0.3M pixels
High image quality
USB Camera module
KBCR-S07VU / S07VUE

Features

  • High-speed transfer
    Compressed transfer mode (JPEG) : 30fps
    Uncompressed transfer mode (YUV) : VGA (30fps)
  • No driver installation is required due to UVC support.
  • Suitable for industrial applications due to small production quantities and long-term stable supply.
  • Full technical support and semi-customization are available.
    (Customized firmware can be loaded into ROM, and lens selection is available.)
  • Trust and result of in-house production in Japan.

KBCR-S07VU / S07VUE

Specifications

Image sensor 1/4-inch CMOS color sensor / rolling shutter
Total number of pixels 640 × 480 pixels
Image area 3.58 × 2.69 mm
Output signal format USB 2.0 (YUV/MJPEG)
Interface 5pin connector
Function Automatic Exposure Control, Automatic Gain Control, Automatic White Balance, and Various image adjustment functions (software control)
Power supply voltage 5.0 V
Power consumption 0.5 W (max.)
Operating temperature -20°C ~ +60°C
Storage temperature -20°C ~ +70°C (lens excluded)

Dimensions (lens mount for M12 board lens attached)


*(α, β, γ) varies depending on the holder/lens.

*Diagram example when lens HPB1007 is mounted.
